Description
Maintain a fresh, comfortable and well-ventilated environment with the Xpelair GX12 Commercial Window Extractor Fan. Designed for demanding commercial applications, this powerful 12-inch (300mm) axial extractor fan delivers high-performance ventilation for kitchens, offices, workshops, warehouses and other commercial premises.
Featuring reversible airflow, a powerful motor and automatic electro-thermal shutters, the Xpelair GX12 provides an effective solution for removing stale air, excess heat, moisture and unwanted odours from larger indoor spaces.
Powerful Commercial Ventilation
The Xpelair GX12 delivers impressive extraction performance of up to 1,546m³/h, making it ideal for commercial environments requiring substantial air movement.
Its high-performance axial motor provides reliable airflow, helping maintain comfortable working conditions in busy commercial kitchens, workshops and other enclosed spaces.
Reversible Intake and Extraction
Unlike conventional extract-only fans, the Xpelair GX12 supports both air extraction and fresh air intake.
When connected to a compatible controller, the fan can be configured to extract stale indoor air or introduce fresh outdoor air, providing greater flexibility for different ventilation requirements.
Two-speed operation is also available when used with a compatible Xpelair FR22/30 controller, allowing ventilation performance to be adjusted to suit the application.
Automatic Electro-Thermal Shutters
The GX12 features integrated electro-thermal shutters that open automatically during operation and close quietly when the fan is switched off.
These shutters help prevent unwanted draughts and reduce uncontrolled airflow when ventilation is not required.
Designed for Commercial Installations
Suitable for installation in single-glazed and compatible double-glazed windows, the Xpelair GX12 features a robust construction designed for dependable commercial use.
The supplied window installation kit includes Xpelair's ladder strip fixing system, helping provide a secure installation.
An integrated safety finger guard offers additional protection, while the positive plug and socket assembly allows convenient isolation during servicing.
Reliable Long-Term Performance
The Xpelair GX12 features a durable external rotor motor designed to maintain consistent airflow performance, even in challenging outdoor conditions.
Its balanced impeller helps minimise vibration, while sealed bearings reduce maintenance requirements.
With powerful extraction, flexible airflow control and a two-year manufacturer guarantee, the Xpelair GX12 is an excellent ventilation solution for commercial and industrial environments.
Key Features
- 12 Inch Commercial Extractor Fan: Designed for kitchens, offices, workshops and other commercial environments.
- Powerful Extraction Performance: Delivers airflow rates of up to 1,546m³/h.
- Reversible Airflow: Supports both air extraction and fresh air intake.
- Two-Speed Capability: Compatible with an optional FR22/30 controller for selectable ventilation speeds.
- Automatic Electro-Thermal Shutters: Open during operation and close quietly when switched off.
- High-Performance Axial Motor: Designed for reliable commercial ventilation.
- Window Installation: Suitable for single and compatible double-glazed windows.
- Window Fitting Kit Included: Supplied with components for secure window installation.
- Integrated Safety Finger Guard: Provides additional protection during operation.
- Positive Plug and Socket Assembly: Allows convenient isolation for servicing.
- Balanced Impeller: Helps reduce vibration during operation.
- Sealed Motor Bearings: Designed for dependable performance with minimal maintenance.
- Two-Year Manufacturer Guarantee: Provides additional peace of mind.
Technical Specifications
- Brand: Xpelair
- Model: GX12
- Manufacturer Reference: 90012AW
- Product Type: Commercial Window Extractor Fan
- Colour: White
- Fan Type: Axial
- Fan Diameter: 300mm (12 Inches)
- Maximum Extraction Rate: 1,546m³/h
- Low-Speed Extraction Rate: 1,091m³/h
- Maximum Intake Rate: 1,117m³/h
- Low-Speed Intake Rate: 772m³/h
- Airflow Direction: Reversible Intake / Extract
- Number of Speeds: 2 with Compatible Controller
- Noise Level: Approximately 50/55dB(A) at 3m
- Power Consumption: 85W
- Voltage: 220–240V
- Shutter Type: Automatic Electro-Thermal
- Window Hole Diameter: 324mm
- Hole Diameter with Wall Liner: 330mm
- Height: 408mm
- Width: 380mm
- Depth: Approximately 168mm
- Weight: 7.9kg
- Installation: Window Mounted
- Manufacturer Guarantee: 2 Years
What's in the Box?
- Xpelair GX12 Commercial Window Extractor Fan
- Window Installation Kit
- Ladder Strip Fixings
- Installation Instructions
